20K-CE20K-GS60K140K
Material100% Stainless Steel (grade 304 (18-8))
Juicing ProcessDual Gear Multi-Stage
Operating Speed85 rpm
Grinding Force10 hp20 hp40 hp
SHG TechnologyYes
LSCS TechnologyYes
MSE TechnologyYes
Pulp RegulatorYes
Size (width x depth x height)800 x 280 x 500680 x 470 x 11201100 x 320 x 11601450 x 360 x 1320
Weight40kg120kg83.5kg150kg
Feed Chute(upper) 129mm
(lower) 57mm
(upper) 231mm
(lower) 70 mm
(upper) 320 mm
(lower) 82 mm
Screw Length173.5 mm303mm408mm
PowerSingle-phase 230V / 50HzThree-phase 230V / 400V / 50Hz
Motor0.5 HP1 HP2 HP
OperationLever type (forward, reverse)Button type (forward, reverse, emergency button)
Extraction Rate
  • Fruits: 80 – 90%
  • Vegetables: 70 – 85%
(depending upon the individual produce and season (moisture content, etc.))
Capacity (per hour, based on carrots)~20kg~60kg~140kg
± 5%, depending on the produce
Country of OriginSouth Korea
Warranty1 year limited
Certifications
  • CE
  • KS

Larger models are available on request.
